Basic Information |
|||
| Top Speed(km/h) | 225/210/225 | Acceleration 0-100km (s) | - |
| Body | |||
| Length (mm) | 4830 | Width (mm) | 1925 |
| Height (mm) | 1620 | Wheelbase(mm) | 2930 |
| Front Track (mm) | 1660 | Rear Track (mm) | 1660 |
| Doors | 5 | Seats | 5 |
| Curb Weight (kg) | 2330/2155/2210 |
Loaded Ground Clearance (mm)
|
145 |
|
Minimum Turning Radius (m)
|
5.85 |
Trunk Capacity (L)
|
- |
|
Electric Motor
|
|||
|
Motor Brand
|
F: YS210XYA/R: TZ200XYT/TZ200XYS/TZ200XYT
|
Number of electric motors
|
Dual/Single/Single |
|
Motor Layout
|
Front+Rear/Rear/Rear
|
Motor Type
|
Front: ACIM/Rear: PMSM/PMSM/PMSM
|
|
Total Motor Power (kW)
|
390/170/230 | Number of Cylinders | - |
| Valves per Cylinder | - |
Total Motor Torque (N·m)
|
690/380/380 |
|
Front Motor Max Power (kW)
|
390/170/230 |
Front Motor Max Torque (N·m)
|
310/360/670 |
|
Battery/Charging
|
|||
|
Battery Type
|
LFP battery
|
Cell Manufacturer
|
FinDreams |
|
Battery Pack Capacity(kWh)
|
80.64/71.8/80.64
|
CLTC EV Range(km)
|
550/550/610 |
|
DC Fast Charging Power (kW)
|
240/150/240 |
AC Charging Power (kW)
|
7
|
| Gearbox | |||
| Gears | 1 | Transmission |
Fixed Gear Ratio
|
| Chassis & Suspension | |||
| Drivetrain | 4WD/RWD/RWD | Front Suspension |
Double Track Control Arm Suspension
|
| Rear Suspension |
5-Link Independent Suspension
|
Four Wheel Drive Type
|
Electronic Four Wheel Drive
|
| Tires & Brake | |||
| Front Brake | Ventilated Disc | Rear Brake |
Ventilated Disc
|
| Parking Brake | Electronic Parking Brake | Front Tire Specification |
245/45 R20
235/50 R19
235/50 R19
|
| Rear Tire Specification |
245/45 R20
255/45 R19
255/45 R19
|
||
| The specifications and configurations provided on this page are for reference only. Actual specifications are subject to the vehicle sold at the dealership. | |||
