Engineered for municipal health institutions, hospitals, and emergency services, the CLW5040XJHTDP Maxus V80 Medical Ambulance delivers optimal transport reliability and advanced patient support
Patient Handling: Outfitted with an emergency loading stretcher, complete with dedicated stretcher pads and stainless-steel loading guides
Oxygen & Pipeline System: Houses a vertical oxygen cabinet with two 10L medical oxygen cylinders, shock-absorbing clamps, concealed oxygen pipelines, dual national-standard outlets, and a humidification bottle
Hygiene & Construction: Built with an easy-to-clean polymer hardtop interior, non-slip wear-resistant medical flooring, a 1000W UV disinfection lamp, top-mounted yellow nylon antibacterial handrails, and a waste bin
Power & Electrical: Features a 1000W pure sine wave inverter, automotive low-voltage wiring harness, 220V/12V AC/DC outlets, LED interior lighting, angle-adjustable spotlights, and rear boarding lights
Seating & Layout Options: Features flexible seating options including rear-facing padded partition seats, forward-facing independent seats, and right-side long soft-padded seats with seatbelts
Partition & Climate: Sealed partition wall with sliding glass windows (suitable for negative pressure configuration), two-way medical ventilation system, and independent cabin heating and cooling
| Category | Specification | Parameter / Detail |
|---|---|---|
| Vehicle Specifications | Product Name | Ambulance-Maxus V80 |
| Product Model | CLW5040XJHTDP | |
| Gross Mass (GVW) | 3,800 kg | |
| Curb Weight | 2,260 kg | |
| Overall Dimensions | 5700, 5910, 5785 × 1998 × 2552, 2762, 2345, 2420 mm | |
| Passenger Capacity | 6–8 persons | |
| Approach / Departure Angle | 26 / 21°, 26 / 14° | |
| Maximum Speed | 150 – 155 km/h | |
| Chassis & Engine | Chassis Model | SH5041XXYA7DB |
| Fuel Type & Emission Standard | Diesel Fuel | GB17691-2018 National VI | |
| Wheelbase | 3,850 mm | |
| Tire Specifications | 215/75R16LT (2 Axles / 4 Tires) | |
| Track Width (Front/Rear) | Front: 1734 mm | Rear: 1728 mm | |
| Axle Load | 1760 / 2040 kg | |
| Safety Systems | ABS 9 / ESP9 / 3550G500, Event Data Recording (EDR) | |
| Medical & Safety Equipment | Patient Transport | Loading stretcher, stretcher pads & guides, ceiling IV infusion rack |
| Oxygen System | Two 10L oxygen cylinders, concealed pipelines, dual national-standard ports, humidification bottle | |
| Electrical & Controls | 1000W Sine Wave Inverter, 220V/12V AC/DC sockets, UV disinfection lamp, intercom system | |
| Signaling & Lighting | 100W alarm speaker, long-strip/micron roof warning light, dual rear flashing lights, adjustable spotlights |
