The dimensions of the Changan Lumin are as follows: length x width x height: 3270 × 1700 × 1545mm, wheelbase: 1980mm, front track: 1470mm, rear track: 1476mm. The vehicle can accommodate 4 people.
The Changan Lumin adopts a lithium iron phosphate battery with a capacity of 12.92kWh. The energy density of the battery reaches 115Wh/kg, and the energy consumption per 100 kilometers is only 9.3kWh. It offers a pure electric range of 301km (CLTC standard).
The Changan Lumin features a high-strength steel energy-absorbing body, providing robust safety protection. Multiple collision beams ensure comprehensive protection. The fully enclosed chassis enhances safety effectively.
Basic Information |
|||
| Top Speed(km/h) | 101 | - | - |
| Body | |||
| Length (mm) | 3270 | Width (mm) | 1700 |
| Height (mm) | 1545 | Wheelbase(mm) | 1980 |
| Front Track (mm) | 1470 | Rear Track (mm) | 1476 |
| Doors | 3 | Seats | 4 |
| Curb Weight (kg) | 930/870/840 |
Loaded Ground Clearance (mm)
|
125/125/150 |
|
Trunk Capacity (L)
|
104-804
|
-
|
-
|
|
Electric Motor
|
|||
|
Motor Brand
|
XTDM29/XTDM29/20
|
Number of electric motors
|
Single |
|
Motor Layout
|
Front |
Motor Type
|
PMSM |
|
Total Motor Power (kW)
|
35/35/30 | Number of Cylinders | - |
| Valves per Cylinder | - |
Total Motor Torque (N·m)
|
87/87/- |
|
Front Motor Max Power (kW)
|
35/35/30 |
Front Motor Max Torque (N·m)
|
87/87/- |
|
Battery/Charging
|
|||
|
Battery Type
|
LFP battery
|
Cell Manufacturer
|
CATL/
Gotion High-tech
/CATL |
|
Battery Pack Capacity(kWh)
|
28.08/17.65/13.41 |
CLTC EV Range(km)
|
301/205/130 |
|
DC Fast Charging Time (min)
|
35 |
DC Charging Capacity (%)
|
30-80
|
|
AC Charging Power (kW)
|
3.3 |
AC Charging Time (h)
|
7/4.6/6
|
|
AC Charging Capacity (%)
|
30-100 |
-
|
-
|
| Gearbox | |||
| Gears | 1 | Transmission |
Fixed Gear Ratio
|
| Chassis & Suspension | |||
| Drivetrain | FWD | Front Suspension | MacPherson Independent Suspension |
| Rear Suspension |
Trailing Arm Non-independent Suspension
|
- | - |
| Tires & Brake | |||
| Front Brake |
Solid Disc
|
Rear Brake | Solid Disc |
| Parking Brake | Electronic Parking Brake | Front Tire Specification |
165/70 R14
|
| Rear Tire Specification |
165/70 R14
|
||
| The specifications and configurations provided on this page are for reference only. Actual specifications are subject to the vehicle sold at the dealership. | |||
