The dimensions of the Haval H9 are 5070 mm in length, 1976 mm in width, and 1930 mm in height, with a wheelbase of 2850 mm and front/rear track of 1610 mm. It can accommodate 5-7 people.
Haval H9 is equipped with a 2.0T direct injection turbocharged gasoline engine, which features technologies such as direct injection, dual-flow turbocharging, and dual VVT variable valve timing. It achieves efficient power with “low speed, high torque,” while also considering strong power and fuel economy. The engine produces a maximum power of 165 kW and a maximum torque of 385 N·m, paired with an 8-speed automatic transmission.
Haval H9 is equipped with front/rear axle electronic control differential locks that can be manually engaged, ensuring stability and reliability. It also has a central multi-plate clutch differential lock that can be engaged to achieve locking functionality.
Basic Information |
|||
| Top Speed(km/h) | 180/170 | WLTC Fuel Economy(L/100km) | 10.7/8.9 |
| Body | |||
| Length (mm) | 5070 | Width (mm) | 1960 |
| Height (mm) | 1930 | Wheelbase(mm) | 2850 |
| Front Track (mm) | 1635 | Rear Track (mm) | 1635 |
| Doors | 5 | Seats | 7 |
| Curb Weight (kg) | 2365/2395 |
Towing Capacity (kg)
|
2500 |
| Engine | |||
| Displacement (mL) | 1967/2370 | Displacement（L） | 2.0/2.4 |
| Intake System | Turbocharged | Engine Layout | Longitudinal |
| Cylinder Arrangement | L | Number of Cylinders | 4 |
| Valves per Cylinder | 4 | Valve Train System | DOHC |
| Maximum Power (kW) | 165/137 | Maximum Horsepower (PS) | 224/186 |
| RPM at Peak Power | 5500/3600 | Maximum Torque (N·m) | 385/490 |
| RPM at Peak Torque |
1800-3600/
1500-2500
|
Fuel Tank Capacity (L) | 80/78 |
| Fuel Grade | 92 | Emission Standard | China 6 |
| Gearbox | |||
| Gears | 8/9 | Transmission | AT |
| Chassis & Suspension | |||
| Drivetrain | 4WD | Front Suspension |
Double Track Control Arm Suspension
|
| Rear Suspension | Multi-Link Independent Suspension |
Four Wheel Drive Type
|
Real-Time All Wheel Drive
|
| Tires & Brake | |||
| Front Brake | Ventilated Disc | Rear Brake |
Ventilated Disc
|
| Parking Brake | Electronic Parking Brake | Front Tire Specification |
265/55 R19
|
| Rear Tire Specification |
265/55 R19
|
||
| The specifications and configurations provided on this page are for reference only. Actual specifications are subject to the vehicle sold at the dealership. | |||
